Plastic Tweezer Tips

A2ABCF

Kit of 2 Carbon fiber tips and 3 screws - tips: curved, very fine, round, flat (for #2ABCFR.SA Tweezers). OAL: 40mm - 1.57". ESD safe

Documents

Datasheet Download Tip material TDS: Download Body material TDS: Download

Where to buy

Information Request

Information request about This product

Where to buy

Kit of 2 Carbon Fiber tips and 3 screws for type 2ABCF tweezers is suitable to applications which require holding a small component firmly. The curved geometry provides maximum visibility and increased ergonomics. The Carbon Fiber reinforced ESD Plastic provides the tweezers with ESD and non-scratching properties.

Product Details

Category

Plastic Tweezer Tips

Tip style

2AB

Tip features

very fine, round, flat

Tip type

curved

Reverse action

no

ESD safe

yes

Body material

CF

Tip material

CF

Product OAL (mm - in)

40.00 - 1.575

Product width (mm - in)

15.00 - 0.591

Product height (mm - in)

3.50 - 0.138

Tip length (mm - in)

40.00 - 1.575

Tip thickness (mm - in)

0.50 - 0.02

Tip width (mm - in)

2.00 - 0.079

Degree of bending

45.0

Net weight (g-lb)

1.0 - 0.002

RoHS compliant

yes
